Spa dimensions (cm): ø240 x 110
Seats: 6
Dry weight: 420 kg
Water volume: 1600 l

Water jets: 34
Air jets: 12
Massage pumps: 2 x 2CV | 1.5kW
Air pump: 400W
Circulation pump: 0.35CV | 0,26kW

• Balboa® system with control panel TP600 (optional AX40 for end users + TP600 for maintenance team)
• Titanium heater 3kW
• Inox structure 316
• Ozonator
• SubLite underwater light
• ChromoLite chromotherapy

OPTION VERSION "INGROUND"

With separate module for pump room with the following equipment:
- Balboa® system
- Massage and air pumps
- Filtration system with sand based filter

NOTE: "Portable" version has a built-in water compensation tank and a pressure filter. "InGround" version with separate module requires purchase and installation of a water compensation tank.

Included in this spa. Choice of colours.

Pack WiFi with app with Gecko® in.touch.
UV system for extra disinfection.
Nordic Insulation | extra insulation noise reduction.
Heat pump 0.64kW input y 3.45kW output.
pH y Cl control system.

• A level base for placement. In the event that there is an unevenness, no matter how slight, insulating polystyrene sheets will be required to level it.
• Perimeter space of approximately 50cm to be able to access the spa in the future for maintenance and repairs.
• Electrical connection: The hydromassage spa must be connected to a circuit protected by a differential switch dedicated only to the spa, without other electrical equipment being powered by this circuit. For the electrical connection (single phase) of the hot tub a 3-way cable is required - the length is determined by the position of the spa with a minimum of 4 metres. All cables that supply the spa must have the same characteristics, and wiring between 4-6mm thick is recommended depending on the spa's equipment. The wiring must be connected to the electrical box to an independent automatic thermal-magnet differential switch dedicated solely to the spa, with amperage depending on the thickness of the wire installed (consult your electrician).
• Water connection: the spa is filled with a garden hose and to empty it, there is a drain point in one of the corners of the spa to which a hose can also be adapted. To facilitate filling the spa, a water point near the spa is recommended. The spa does not come with automatic emptying/filling. It does not automatically fill or empty or require a drain under the spa.
• A building permit is not required to install the "Portable" version. For the "InGround" version, a building permit for the hole may be required. Also a permit may be required to place the crane in public road space.
• Wiring, pipes and small materials in case the spa and the machine room are far apart.
