Dimensions (cm): 580 x 230 x 120 (1010) y 580 x 230 x 156 (1011)
Seats in spa area: 4
Dry weight: 1100 kg
Water volume: 6500 l

SPA AREA:
Water jets: 60
Air jets: 8
Massage pumps: 2 x 1.5CV | 1.1kW
Air pumps: 400W
Circulation pump: 0.50CV | 0.37kW

SWIM AREA:
Countercurrent pumps: 3 x 3CV | 2.2kW
Circulation pump: 1CV | 0.75kW

• Gecko® control system with control panel in.k1001
• Titanium heater 3kW
• Galvanised steel structure
• Ozonator 50mg/h in spa area | 200mg/h in swim area
• SubLite underwater light in both areas
• ChromoLite chromotherapy in both areas
• Nordic Insulation
• 2 headrests in spa area

Included in this swimspa. Choice of colours.

Hand Rail for counter current area.
Lit waterfall 60cm ein swim area.
Fusion Stereo II | with Gecko® in.stream + speakers + subwoofer.
Gecko® in.clear | salt bromine disinfection system.
Pack WiFi with app with Gecko® in.touch.
UV system.
Roll-on cover.
Heat pump 0.64kW input y 3.45kW output.
Automatic pH and Cl feeding system.
Fitness equipment.

• A level base for placement. In the event that there is an unevenness, no matter how slight, insulating polystyrene sheets will be required to level it.
• Perimeter space of approximately 60cm to be able to access the swimspa in the future for maintenance and repairs.
• Electrical connection: The swimspa spa must be connected to a circuit protected by a differential switch dedicated only to the swimspa, without other electrical equipment being powered by this circuit. For the electrical connection (single phase) of the hot tub a 3-way cable is required - the length is determined by the position of the spa with a minimum of 6 metres. All cables that supply the spa must have the same characteristics, and wiring between 4-6mm thick is recommended depending on the swimspa's equipment. The wiring must be connected to the electrical box to an independent automatic thermal-magnet differential switch dedicated solely to the swimspa, with amperage depending on the thickness of the wire installed (consult your electrician).
• Water connection: the swimspa is filled with a garden hose and to empty it, there is a drain point in one of the corners of the swimspa to which a hose can also be adapted. To facilitate filling the swimspa, a water point near the spa is recommended. The swimspa does not come with automatic emptying/filling. It does not automatically fill or empty or require a drain under the spa.
• A building permit is not required for its placement. But a permit may be required to place the crane in public road space.
